| Model | IPC-A4 |
| EDP# | 621610 |
| Applied Voltage | AC6.0kV (p-p) |
| Input Voltage | DC24V±5% |
| Power Consumption | 17W |
| Current Consumption | 700mA |
| Noise | 86.5dB |
| Weight | 6.0kg |
| Material | Booth: Steel, Hard PVC plates Plates: Stainless Steel Adhesive Gel: Polyurethane |
| Ion generation method | Corona discharge N-2 Pinpoint Nozzel ionizer |
| Applied Fluid | Clean air (0.1-0.3MPa) |
| Pulse | Continuos mode High-frequency mode (cycle length: 100msec, pulse width: 40msec) Low-frequency mode (cycle length: 250msec, pulse width: 100msec) |
| Timer | 1,2,5,10,30-second auto-off timer (selectable by DIP switch) |
| Ozone generation | 0.05 ppm or less (measured 50mm from device) |
| Dimensions | 350H x 300W x 250D |
| Operating Humidity | 35~65%RH (non-condensing) |
| Operating Temp | 5~40°C |
| Air consumption | 187/min (0.3MPa, Continuous Mode) |
| Accessories | Power Supply Transformer (input 100-240VAC, Output:24 VDC) Moutning Bracket for N-2 Electrode Needle Replacement Screwdriver |
